2-stage rotary snow blowers with a spiral cutter and thrower for the smaller carriers and tractors with a motor power in the range approx. 30-60 kW.
  • The snow blower overload protection is a shear pin on the drive shaft (W 550) or a slip clutch (W 5560

Gallery

Specifications



W 550/1300

W 550/1500

W 550/1700

W 5560/1500

W 5560/1600

W 5560/1800

W 5560/2000

drum (working) width

mm

1300

1500

1700

1500

1600

1800

2000

drum diameter

mm

550

550

550

550

550

550

550

ejection-wheel diameter

mm

500

500

500

600

600

600

600

max. height of the snow layer

mm

810

810

810

810

810

810

810

weight

kg

360

380

400

400

430

490

560

carrier vehicle power range

kW

30 – 60

30 – 60

30 – 60

30 – 60

30 – 60

30 – 60

30 - 60
